TP-Link VIGI NVR1104H-4P 4-Channel PoE 4K Network Video Recorder H.265+

The TP-Link VIGI NVR1104H-4P is a 4-channel PoE network video recorder supporting up to 4K resolution with H.265+ compression. Designed for home and small business surveillance, it captures detailed footage while reducing bandwidth and storage requirements.

With four built-in PoE ports, it delivers both power and data over a single Ethernet cable, simplifying installation and reducing cable clutter. The NVR supports one SATA HDD up to 10TB for extended recording retention and includes remote access via the VIGI mobile app or web portal.

It offers 4-channel video input, 4 PoE ports with 53W total power, H.265+/H.265/H.264+/H.264 compression, 1 Gigabit Ethernet port, HDMI and VGA outputs for up to 4K display, and two-way audio support. The operating temperature range is 0°C to 40°C.

Channels	4 Channel Video Input
Resolution Support	Up to 4K (3840 x 2160)
Video Compression	H.265+/H.265/H.264+/H.264
PoE Ports	4 x PoE Ports (802.3 af/at, 53W total)
Storage Capacity	1 SATA HDD (up to 10TB)
Network Ports	1 x 10/100/1000 Mbps Ethernet Port
Audio Input/Output	1 Input, 1 Output (two-way audio)
Video Output	1 x VGA, 1 x HDMI (up to 4K, synchronous)
USB Ports	2 x USB 2.0
Operating System	Embedded Linux OS
Power Supply	DC 12V, 2A
Operating Temperature	0°C to 40°C
Dimensions	21.9 x 21.9 x 5.1 cm
Weight	0.6 kg
