TP-Link Omada ER707-M2 Gigabit VPN Router with PoE+

The TP-Link Omada ER707-M2 is a Gigabit VPN Router with PoE+ ports and integrated Omada controller capability, designed for business networks requiring secure remote access and centralised management. It features four PoE+ ports compliant with IEEE 802.3af/at, enabling direct power delivery to IP cameras, access points, and VoIP phones without separate adapters.

Comprehensive VPN support includes IPsec, L2TP, and PPTP protocols with throughput up to 400 Mbps, ensuring encrypted site-to-site and client-to-site connections. The router integrates with the Omada SDN Cloud Controller for centralised monitoring, configuration, and troubleshooting from a single interface.

Equipped with one 2.5G RJ45 WAN port, one 2.5G RJ45 WAN/LAN port, one Gigabit SFP WAN/LAN port, and four Gigabit RJ45 WAN/LAN ports, the ER707-M2 delivers high-speed connectivity for internet access, file sharing, and cloud applications. Security features include SPI firewall, DoS protection, and IP/MAC filtering.

Model	TP-Link Omada Gigabit VPN Router with PoE+ Ports (ER707-M2)
WAN Ports	1 × 2.5G RJ45 WAN, 1 × 2.5G RJ45 WAN/LAN, 1 × Gigabit SFP WAN/LAN
LAN Ports	4 × Gigabit RJ45 WAN/LAN (configurable)
PoE+ Ports	4 × PoE+ (IEEE 802.3af/at)
VPN Support	IPsec, L2TP, PPTP, L2TP over IPsec, SSL VPN, OpenVPN
VPN Throughput	Up to 400 Mbps
Concurrent Sessions	500,000
Controller Integration	Omada SDN Cloud Controller
Security Features	SPI Firewall, DoS Protection, IP/MAC Filtering, Policy-based Firewall
Mounting	Desktop or Wall Mount
Operating Temperature	0°C to 40°C
Power Supply	12V DC, 2A
USB Port	1 × USB 2.0 (for 4G LTE backup dongle)
