Panasonic U System 4 Aircon (9K X2 + 12K + 18K)

Panasonic U System 4 Aircon (9K X2 + 12K + 18K)

CU-4U28YBZ

  • Model CU-4U28YBZ
  • Cooling Capacity (min-max) 8.00 (2.80 ~ 10.20) kW
  • 27,300 (9,550 ~ 34,800) Btu/h
  • Power Source Single Phase, 220V-240V, 50Hz
  • Maximum Connectable Capacity 16.2 kW
  • Maximum Connectable Indoor 4 Units
  • Running Current 9.4 - 8.6 A
  • Power Input (min-max) 2,000 (540 - 3,200) W
  • EER (min-max) 13.65 (17.69 - 10.88) Btu/hW
  • COP (min-max) 4.00 (5.19 - 3.19) W/W
  • Weighted COP 4.75 W/W

CS-MPU9YKZ

  • Model CS-MPU9YKZ
  • Cooling Capacity 2.8 kW
  • 9,550 Btu/h
  • Power Source Single Phase, 220V-240V, 50Hz
  • Sound Pressure Level High/Low 43/28 dB(A)
  • Air Circulation High 12.7 m³/min (450 ft³/min)
  • Height 290 mm
  • Width 779 mm
  • Depth 209 mm

    CS-MPU12YKZ

    • Model CS-MPU12YKZ
    • Cooling Capacity 3.5 kW
    • 11,900 Btu/h
    • Power Source Single Phase, 220V-240V, 50Hz
    • Sound Pressure Level High/Low 44/28 dB(A)
    • Air Circulation High 13.1 m³/min (460 ft³/min)
    • Height 290 mm
    • Width 779 mm
    • Depth 209 mm
    • Net Weight 8 kg


      CS-MPU18YKZ

      • Model CS-MPU18YKZ
      • Cooling Capacity 5 kW
      • 17,100 Btu/h
      • Power Source Single Phase, 220V-240V, 50Hz
      • Sound Pressure Level High/Low 45/34 dB(A)
      • Air Circulation High 13.3 m³/min (470 ft³/min)
      • Height 290 mm
      • Width 779 mm
      • Depth 209 mm
      • Net Weight 9 kg
      • Refrigerant Pipe Diameter Liquid Side ø 6.35 mm Gas Side ø 9.52 mm
      • Power Supply Outdoor





          $1,568.00

          Original: $4,480.00

          -65%
          Panasonic U System 4 Aircon (9K X2 + 12K + 18K)—

          $4,480.00

          $1,568.00

          Product Information

          Shipping & Returns

          Description

          CU-4U28YBZ

          • Model CU-4U28YBZ
          • Cooling Capacity (min-max) 8.00 (2.80 ~ 10.20) kW
          • 27,300 (9,550 ~ 34,800) Btu/h
          • Power Source Single Phase, 220V-240V, 50Hz
          • Maximum Connectable Capacity 16.2 kW
          • Maximum Connectable Indoor 4 Units
          • Running Current 9.4 - 8.6 A
          • Power Input (min-max) 2,000 (540 - 3,200) W
          • EER (min-max) 13.65 (17.69 - 10.88) Btu/hW
          • COP (min-max) 4.00 (5.19 - 3.19) W/W
          • Weighted COP 4.75 W/W

          CS-MPU9YKZ

          • Model CS-MPU9YKZ
          • Cooling Capacity 2.8 kW
          • 9,550 Btu/h
          • Power Source Single Phase, 220V-240V, 50Hz
          • Sound Pressure Level High/Low 43/28 dB(A)
          • Air Circulation High 12.7 m³/min (450 ft³/min)
          • Height 290 mm
          • Width 779 mm
          • Depth 209 mm

            CS-MPU12YKZ

            • Model CS-MPU12YKZ
            • Cooling Capacity 3.5 kW
            • 11,900 Btu/h
            • Power Source Single Phase, 220V-240V, 50Hz
            • Sound Pressure Level High/Low 44/28 dB(A)
            • Air Circulation High 13.1 m³/min (460 ft³/min)
            • Height 290 mm
            • Width 779 mm
            • Depth 209 mm
            • Net Weight 8 kg


              CS-MPU18YKZ

              • Model CS-MPU18YKZ
              • Cooling Capacity 5 kW
              • 17,100 Btu/h
              • Power Source Single Phase, 220V-240V, 50Hz
              • Sound Pressure Level High/Low 45/34 dB(A)
              • Air Circulation High 13.3 m³/min (470 ft³/min)
              • Height 290 mm
              • Width 779 mm
              • Depth 209 mm
              • Net Weight 9 kg
              • Refrigerant Pipe Diameter Liquid Side ø 6.35 mm Gas Side ø 9.52 mm
              • Power Supply Outdoor
