Panasonic U System 2 Aircon (9K + 12K)

CU-2U18YBZ

• Model CU-2U18YBZ
• Cooling Capacity (min-max) 5.10 (1.50 ~ 6.10) kW
• 17,400 (5,120 ~ 20,800) Btu/h
• Power Source Single Phase, 220V-240V, 50Hz
• Maximum Connectable Capacity 8.5 kW
• Maximum Connectable Indoor 2 Units
• Running Current 6.1 - 5.6 A
• Power Input (min-max) 1,310 (250 - 1,900) W
• EER (min-max) 13.28 (20.48 - 10.95) Btu/hW
• COP (min-max) 3.89 (6.00 - 3.21) W/W
• Weighted COP 4.75 W/W

CS-MPU9YKZ

• Model CS-MPU9YKZ
• Cooling Capacity 2.8 kW
• 9,550 Btu/h
• Power Source Single Phase, 220V-240V, 50Hz
• Sound Pressure Level High/Low 43/28 dB(A)
• Air Circulation High 12.7 m³/min (450 ft³/min)
• Height 290 mm
• Width 779 mm
• Depth 209 mm

CS-MPU12YKZ

• Model CS-MPU12YKZ
• Cooling Capacity 3.5 kW
• 11,900 Btu/h
• Power Source Single Phase, 220V-240V, 50Hz
• Sound Pressure Level High/Low 44/28 dB(A)
• Air Circulation High 13.1 m³/min (460 ft³/min)
• Height 290 mm
• Width 779 mm
• Depth 209 mm
• Net Weight 8 kg
