LG LAEC018-GN2 163" LG LED Signage All-in-One Smart Series

Physical Parameter

• Pixel Configuration Single SMD
• Pixel Pitch (mm) 1.88
• Module Dimensions (W x H, mm) 300 × 168.75
• Screen Resolution (WxH) 1,920 x 1,080
• Screen Dimension (W x H x D,mm) 3,604 × 2,029 × 45.5 (Thickest 81)
• Screen Weight (kg) 190
• No. of Modules per Screen (W x H) 12 × 12 (Total 144)
• Screen Surface Area (㎡) 7.29
• Physical Pixel Density (pixels/m²) 284,444
• Flatness of Cabinet ±0.2 mm
• Cabinet Material Aluminum
• Service Access Front

Optical Parameter

• Max Brightness (After Calibration, nit) 500
• Color Temperature (K) 3,200 - 9,300
• Visual Viewing Angle (Horizontal/Vertical) 160 / 160
• Brightness Uniformity 98%
• Color Uniformity ±0.015Cx,Cy
• Contrast Ratio 3000 : 1
• Processing Depth (bit) 16 (HDR10, HDR10 Pro)

Power Consumption (W/Screen, Max.) 2,200

• Power Consumption (W/Screen, Avg.) 880
• Power Consumption (W/m², Max.) 302
• Power Consumption (BTU/h/Screen, Max.) 7,506
• Power Consumption (BTU/h/Screen, Avg.) 3,004
• Power Consumption (BTU/h/㎡, Max.) 1,030
• Power Supply (V) 100 to 240
• Frame Rate (Hz) 50 / 60
• Refresh Rate (Hz) 3,000
