LG 55EJ5K 55" Flat OLED Signage

Panel

• Screen Size: 55”
• Panel Technology: OLED
• Native Resolution: 1,920 X 1,080 (FHD)
• Brightness: 150 / 400 nit (APL 100% / 25%)
• Contrast Ratio: 150,000 : 1
• Color gamut: BT709 120%
• Viewing Angle (H x V): 178 × 178
• Color Depth: 1.07 Billon Colors (10 bit (R))
• Response Time: 1 ms (G to G), 8 ms (MPRT)
• Surface Treatment (Haze): Hard Coating (2 H), Reflectance Typ. 1.2%
• Operation Hours (Hours / Days): 18 / 7 (Moving Content Only)
• Portrait / Landscape: Yes / Yes

Mechanical Specification

• Bezel Color: Black
• Bezel Width: 0.9 mm (Even Bezel) (Off Bezel)
  5.3 / 5.3 / 5.3 / 11.0 mm (T/R/L/B) (On Bezel)
• Weight (Head): 6.5 kg (Head)
  3.4 kg (Signage Box)
• Monitor Dimensions (W × H × D): 1,220.3 × 696.8 × 4.9 mm (Head)
  782.8 × 238.4 × 34.7 mm (Signage Box)

Feature

• Key Feature: Internal Memory (16 GB), Sensor (Temperature Sensor), webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected® (Network based control.)), Power (PM Mode, Wake on LAN), HDMI-CEC (Compatibility may differ by equipment.), SI Server Setting, Pro:Idiom

Environment Conditions

• Operation Temperature: 0 to 40
• Operation Humidity: 10%-80%

Power

• Power Supply: AC 100-240 V~, 50/60 Hz
• Power Type: Built-in Power

Power Consumption

• Typ./Max.: 116W (IEC 62087) / 318 W
• BTU (British Thermal Unit): 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)

Standard (Certification)

• Safety: IEC 60950-1 / EN 60950-1 / UL 60950-1
• EMC: FCC Class "A" / CE / KC
• ErP: Yes

Software Compatibility

• SuperSign CMS: Yes
• SuperSign Control / Control+: Yes
• SuperSign WB: Yes
• SuperSign Media Editor: Yes
• LG ConnectedCare: Yes * The availability can differ by region.

Connectivity

• Input: HDMI (HDCP 1.4), DP (HDCP 1.3), RS-232C In, RJ45 (LAN), IR In (External IR Receiver), USB 2.0 Type A (2)
• Output: DP Out, Audio Out, RS-232C Out (w / IR Out), RJ45 (LAN)

Language

• OSD: English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Arabic

Accessory

• Basic: Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS-232C Gender, FFC Cables (1,600 mm × 4 ea for Connection between Panel and Signage Box), DP Cable (2 M), LAN Cable (1.5 M), RS-232 Cable (4P-4P, 1.5 M), LC Cable (VLC, 3 M), Wall Fixer (4 ea), Wall Fixer Install Guide, Install Guide Sheet (2 ea), Tape (10 ea for Cabling / 2 ea for Dust Proof), Screw (M4 × L25, 10 ea / M3 × L5.5, 8 ea)
