Cooler Master MCB-CM694-KG5N-S00 CM MASTERBOX CM694 ATX Case With T.G
- Model Number MCB-CM694-KG5N-S00 (TG)
- Series MasterBox Series
- Size Mid Tower
- Color(s) Black
- Materials Steel, Plastic, Tempered Glass, Mesh
- Dimensions (L x W x H) Steel: 493mm x 220mm x 506mm (incl. Protrusions), Steel: 482mm x 220mm x 477mm (excl. Protrusions), TG: 493mm x 224mm x 506mm (incl. Protrusions), TG: 482mm x 224mm x 477mm (excl. Protrusions)
- Motherboard Support Mini ITX, Micro ATX, ATX, E-ATX
- Expansion Slots 7
- 5.25" Drive Bays 2
- 2.5" / 3.5" Drive Bays (Combo) 6 (3x drive cages)
- 2.5" Drive Bays 8 (2 + 6 combo)
- I/O Panel 2x USB 3.0 Type A, 1x USB 3.1 Type-C, 1x 3.5mm Headset Jack (Audio+Mic)
- Pre-installed Fans - Front 2x 120mm Fan (1200 RPM ± 200 RPM, 3 pin connector)
- Pre-installed Fans - Rear 1x 120mm fan (1200 RPM ± 200 RPM, 3 pin connector)
- Fan Support - Front 3x 120mm / 2x 140mm (wo/ODD), 2x 120mm / 2x 140mm (w/ODD)
- Fan Support - Top 3x 120mm, 2x 140mm
- Fan Support - Rear 1x 120mm
- Radiator Support - Front 120mm*, 140mm*, 240mm*, 280mm**, 360mm** (*remove 2 out of 3 drive cages) (**remove 2 out of 3 drive cages & ODD cage)
- Radiator Support - Top 120mm, 140mm, 240mm, 280mm, 360mm, (mount radiator below the bracket & fans above the bracket for maximum compatibility)
- Radiator Support - Rear 120mm
- Clearance - CPU Cooler 171mm
- Clearance - GFX 410mm/16.1", 350mm (with stabilizer), 280mm (with stabilizer + drive cage)
- Clearance - PSU 276mm, 160mm (drive cage rear position)
- Power Supply Support Bottom Mount, ATX PS2
- Dust Filters Top, Front, Bottom
- Cable Routing 27-29mm
$61.90
Original: $176.86
-65%Cooler Master MCB-CM694-KG5N-S00 CM MASTERBOX CM694 ATX Case With T.G—
$176.86
$61.90Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
- Model Number MCB-CM694-KG5N-S00 (TG)
- Series MasterBox Series
- Size Mid Tower
- Color(s) Black
- Materials Steel, Plastic, Tempered Glass, Mesh
- Dimensions (L x W x H) Steel: 493mm x 220mm x 506mm (incl. Protrusions), Steel: 482mm x 220mm x 477mm (excl. Protrusions), TG: 493mm x 224mm x 506mm (incl. Protrusions), TG: 482mm x 224mm x 477mm (excl. Protrusions)
- Motherboard Support Mini ITX, Micro ATX, ATX, E-ATX
- Expansion Slots 7
- 5.25" Drive Bays 2
- 2.5" / 3.5" Drive Bays (Combo) 6 (3x drive cages)
- 2.5" Drive Bays 8 (2 + 6 combo)
- I/O Panel 2x USB 3.0 Type A, 1x USB 3.1 Type-C, 1x 3.5mm Headset Jack (Audio+Mic)
- Pre-installed Fans - Front 2x 120mm Fan (1200 RPM ± 200 RPM, 3 pin connector)
- Pre-installed Fans - Rear 1x 120mm fan (1200 RPM ± 200 RPM, 3 pin connector)
- Fan Support - Front 3x 120mm / 2x 140mm (wo/ODD), 2x 120mm / 2x 140mm (w/ODD)
- Fan Support - Top 3x 120mm, 2x 140mm
- Fan Support - Rear 1x 120mm
- Radiator Support - Front 120mm*, 140mm*, 240mm*, 280mm**, 360mm** (*remove 2 out of 3 drive cages) (**remove 2 out of 3 drive cages & ODD cage)
- Radiator Support - Top 120mm, 140mm, 240mm, 280mm, 360mm, (mount radiator below the bracket & fans above the bracket for maximum compatibility)
- Radiator Support - Rear 120mm
- Clearance - CPU Cooler 171mm
- Clearance - GFX 410mm/16.1", 350mm (with stabilizer), 280mm (with stabilizer + drive cage)
- Clearance - PSU 276mm, 160mm (drive cage rear position)
- Power Supply Support Bottom Mount, ATX PS2
- Dust Filters Top, Front, Bottom
- Cable Routing 27-29mm
